Alcatel c701 success format and write imei...[Reference]

[BLIND]

Problem Restart :
Infinity box used:
tick Format and after that write imei

heres the pinout:




COM12 [VCP0] selected
module v3.25
Device: Alcatel-C701X, C701A
Checking data, wait...
advanced flash detection enabled
Action: "repair imei"
new imei: 353205012785661
====> Boot ...
Press and HOLD Power button now !
19200 fixed
Connecting, wait...
Initializing [6226:8A03:8A02]...
CPU: MT6226
chip: 0031:B565:A000
status: 01
boot packet size: 0400
Release Power button now !
Boot Done
====> Initialize ...
detecting chip #00 in region #00...
flash: 01227E22302200:2BEA0000000000
flash: Amd AMD/Fujitsu std [D 0004x008000 00FEx020000 0004x008000] 32Mb
otp offset: 00000000
number of flash chip/regions detected: 01/01
Initialize Done
====> Set baud ...
921600
Set baud Done
====> Initialize bootcode ...
Initialize bootcode Done
====> Check firmware integrity ...
usb bootloader detect...
..
usb bootloader detect (phase #2)...
..
usb bootloader (chip) is absent
searching rom info...
search rom info finished
rom info structure: 2nd [enhanced] generation
TCL-ID is absent
startup code area #1 is Ok
startup code area #1 backup saved: C:\Program Files\InfinityBox\MModule\backup_security\id.8CB78 9E0.[JRD26_06A_PCB01_GPRS_MT6226_S02.MAUI_06A_W06_52_SP 1_V17.BIN_1CC48DF6].rpl
rom info detection finished
device-id: 8CB789E0
rom info ver: 05
sw version: JRD26_06A_PCB01_GPRS_MT6226_S02.MAUI_06A_W06_52_SP 1_V17.BIN
project-id: MAUI.06A.W06.52.SP1.V17, F68DC41C
code offset: 00000000
ffs offset/size [01]: 01200000/00E00000
rom info structure: 2nd [enhanced] generation
TCL-ID is absent
ffs/eeprom address assigned: 01200000
startup code area #1 check...
startup code area #1 fixed
sec info (detailed) detection...
searching sec info#1...
search sec info#1 finished
sim-lock status: disabled
product id: JRD_Communication_Inc_C7_Series
area1 is valid
area2 is valid
area3 is valid
area4 is valid
searching sec info#2...
.
search sec info#2 finished
Check firmware integrity Done
====> Check firmware content ...
Check firmware content Done
====> Backup required data ...
original imei: 35320501278566
flash: 01227E22302200:2BEA0000000000
Backup required data Done
====> Patch required data ...
.....................................
pass #1
firmware remap[01]: 08000000
...........................
Patch required data Done
====> Special operation ...
Special operation Done
====> Write ...
flash: 01227E22302200:2BEA0000000000
flash: 01227E22302200:2BEA0000000000
Write: imei
sec info (fast) detection...
searching sec info#1...
search sec info#1 finished
searching sec info#2...
.
search sec info#2 finished
security area (sec info, part #2) calculation...
identification header detected
relocation table detected
name table detected
customization: CC18BF20
customization name adjusted
customization detected: CC18BF20
customization: CC18BF20
error: can't calculate security area (sec info, part #2), existing data will be used
Check support area for updates !
security area (sec info, part #2) calculation done
security area (sec info, part #1) calculation...
..................security area (sec info, part #1) detecting size...
security area (sec info, part #1) detecting parameters...
security area (sec info, part #1) encoding...
done
flash: 01227E22302200:2BEA0000000000
flash: 01227E22302200:2BEA0000000000
Write: security area (sec info, part #1)
security area (sec info, part #1) calculation done
Write Done
====> Finalization ...
ffs formatting...
flash: 01227E22302200:2BEA0000000000
Finalization Done
file saved: C:\Program Files\InfinityBox\MModule\backup_security\Alcatel-C701X,C701A_JRD26_06A_PCB01_GPRS_MT6226_S02.MAUI_0 6A_W06_52_SP1_V17__system_log_8CB789E0_1CC48DF6_20 100316-140852.B0X.bin
Finished, time used: 3 min 42 sec
Remove/Install battery now !
File system has been modified !
It is need to press and HOLD phone "Power" button
during long time (up to 1 min) to make phone Powered-On !​
