REFERENCE Default G9 nokia china phone phone lock DONE.

[DJVON_09]

sabi ng customer di daw maopen ang phone nya.

yun pala may password, nakalimutan raw nya.

ito ang pic ng unit:



kaya ginawa ko format sa aking volcano.

PROCEDURE:

open volcano

click Mstar

click readflash and then click RUN(back up ko muna baka sakali.)

logs ng back up ko.

kaya ginawa ko format sa aking volcano.

PROCEDURE:

open volcano

click Mstar

click readflash and then click RUN(back up ko muna baka sakali.)

logs ng back up ko.

kaya ginawa ko format sa aking volcano.

PROCEDURE:

open volcano

click Mstar

click readflash and then click RUN(back up ko muna baka sakali.)

logs ng back up ko.

2012-12-04 1:53:54 PM >>Pinouts setting complete!
2012-12-04 1:53:55 PM >>Connecting to phone...
1290492012 1:53:55 PM >>Connecting to phone...
2012-12-04 1:53:55 PM >>Connection success!
1290492012 1:53:55 PM >>Connection success!
2012-12-04 1:53:55 PM >>Boot downloading...
1290492012 1:53:55 PM >>Boot downloading...
2012-12-04 1:53:55 PM >>CPU ID:00000013
1290492012 1:53:55 PM >>CPU ID:00000013
2012-12-04 1:53:55 PM >>
1290492012 1:53:55 PM >>
2012-12-04 1:53:56 PM >>Flash Type: SPANSION_S71WS128P
1290492012 1:53:56 PM >>Flash Type: SPANSION_S71WS128P
2012-12-04 1:53:56 PM >>Flash ID: 0001440000000000
1290492012 1:53:56 PM >>Flash ID: 0001440000000000
2012-12-04 1:53:56 PM >>Flash Size: 01000000h
1290492012 1:53:56 PM >>Flash Size: 01000000h
2012-12-04 1:53:56 PM >>Read Size: 01000000h(16M)
1290492012 1:53:56 PM >>Read Size: 01000000h(16M)
2012-12-04 1:53:56 PM >>CPU : 8535x/8533_series
1290492012 1:53:56 PM >>CPU : 8535x/8533_series
2012-12-04 1:53:56 PM >>Flash Reading...
1290492012 1:53:56 PM >>Flash Reading...
2012-12-04 1:54:49 PM >>Phone Lock or SIM Lock:
2012-12-04 1:54:49 PM >>0040
2012-12-04 1:54:49 PM >>0042
2012-12-04 1:54:49 PM >>0000
2012-12-04 1:54:49 PM >>7515
2012-12-04 1:54:49 PM >>9961
2012-12-04 1:54:49 PM >>7518
2012-12-04 1:54:49 PM >>Anti-theft lock:
2012-12-04 1:54:50 PM >>100000
2012-12-04 1:54:50 PM >>466099
2012-12-04 1:54:50 PM >>91796
2012-12-04 1:54:50 PM >>98843
2012-12-04 1:54:50 PM >>screen lock:
2012-12-04 1:54:50 PM >>210
2012-12-04 1:55:04 PM >>The data has been saved in C:\Documents and Settings\samsung\Desktop\volcano 1.6.8\g9.bin, size: 16 M.

and then format ko na sya

ito ang logs.

2012-12-04 1:55:41 PM >>Detection initiated...
2012-12-04 1:55:43 PM >>Vcc: 12
2012-12-04 1:55:43 PM >>Gnd: 6 10
2012-12-04 1:55:43 PM >>Analyzing D+ and D-...
2012-12-04 1:55:48 PM >>D+ = 3, D- = 1
2012-12-04 1:55:48 PM >>Detection D+/D- with 3.86 seconds!
2012-12-04 1:55:48 PM >>Analyzing USB device, please wait...
2012-12-04 1:56:02 PM >>Found [MSTAR]USB device:GCREADER USB Device,(VID_1B20&PID_0300)
2012-12-04 1:56:02 PM >>Setting...
2012-12-04 1:56:05 PM >>Find USB device:GCREADER USB Device, (VID_1B20&PID_0300)
2012-12-04 1:56:05 PM >>Pinouts setting complete!
2012-12-04 1:56:05 PM >>Connecting to phone...
1290492012 1:56:05 PM >>Connecting to phone...
2012-12-04 1:56:05 PM >>Connection success!
1290492012 1:56:05 PM >>Connection success!
2012-12-04 1:56:06 PM >>Boot downloading...
1290492012 1:56:06 PM >>Boot downloading...
2012-12-04 1:56:06 PM >>Flash Type: SPANSION_S71WS128P
1290492012 1:56:06 PM >>Flash Type: SPANSION_S71WS128P
2012-12-04 1:56:07 PM >>Flash ID: 0001440000000000
1290492012 1:56:07 PM >>Flash ID: 0001440000000000
2012-12-04 1:56:07 PM >>Flash Size: 01000000h
1290492012 1:56:07 PM >>Flash Size: 01000000h
2012-12-04 1:56:08 PM >>Flash Erasing...
1290492012 1:56:08 PM >>Flash Erasing...finish

my finish product::x



at ito buo pa rin imei nya



sensya na malabo yung pic...
